NCF 60 Hz

NCF 60 Hz

The Nederman NCF Fans have direct drive motors which means a safe and cost-effective operation. Installing an energy efficient NCF fan with our other Nederman products saves time and reduces energy costs. It is a centrifugal fan designed for use in all types of industrial process and ventilation systems, mounted indoor as well as outdoor. The fan is equipped with vibration absorbers as standard.

Technical data
Certifications CE
Protection class IP 55
Installation Outdoor, Indoor
Material Sheet metal, painted grey, RAL 7045
Ambient temperature range -30 to +40 °C (22 F to 104 F)
Operating Temperature Max. 60 °C
Frequency (Hz) 60

Models30

    FAN NCF 30/15

    ArtNo: 14521828

    Amperage (A)
    8,6
    Noise level (dB(A))
    69 db(A) at 2500 m³/h
    No of phases
    3
    Power (kW)
    2,2
    Power Voltage (V)
    208
    Weight (kg)
    67
    FAN NCF 30/20

    ArtNo: 14521928

    Amperage (A)
    11,5
    No of phases
    3
    Power (kW)
    3
    Power Voltage (V)
    208
    Weight (kg)
    85
    FAN NCF 30/25

    ArtNo: 14522028

    Amperage (A)
    15,1
    Noise level (dB(A))
    74 db(A) at 4000 m³/h
    No of phases
    3
    Power (kW)
    4
    Power Voltage (V)
    208
    Weight (kg)
    105
    FAN NCF 40/25

    ArtNo: 14522128

    Amperage (A)
    18,7
    Noise level (dB(A))
    75 db(A) at 4000 m³/h
    No of phases
    3
    Power (kW)
    5,5
    Power Voltage (V)
    208
    Weight (kg)
    110
    FAN NCF 50/25

    ArtNo: 14522228

    Amperage (A)
    18,7
    Noise level (dB(A))
    78 db(A) at 3500 m³/h
    No of phases
    3
    Power (kW)
    5,5
    Power Voltage (V)
    208
    Weight (kg)
    112
    FAN NCF 80/20

    ArtNo: 14522328

    Amperage (A)
    26,2
    Noise level (dB(A))
    77 db(A) at 6000 m³/h
    No of phases
    3
    Power (kW)
    7,5
    Power Voltage (V)
    207
    Weight (kg)
    150
    Fan NCF 120/15

    ArtNo: 14522428

    Amperage (A)
    38,4
    Noise level (dB(A))
    85 db(A) at 10000 m³/h
    No of phases
    3
    Power (kW)
    11
    Power Voltage (V)
    208
    Weight (kg)
    161
    Fan NCF 120/25

    ArtNo: 14522528

    Amperage (A)
    52
    Noise level (dB(A))
    82 db(A) at 8000 m³/h
    No of phases
    3
    Power (kW)
    15
    Power Voltage (V)
    208
    Weight (kg)
    232
    FAN NCF 160/25

    ArtNo: 14522628

    Amperage (A)
    66,4
    Noise level (dB(A))
    84 db(A) at 10000 m³/h
    No of phases
    3
    Power (kW)
    18,5
    Power Voltage (V)
    208
    Weight (kg)
    292
    FAN NCF 30/15

    ArtNo: 14522728

    Amperage (A)
    7,8/3,9
    Noise level (dB(A))
    69 db(A) at 2500 m³/h
    No of phases
    3
    Power (kW)
    2,2
    Power Voltage (V)
    230/460
    Weight (kg)
    67
    FAN NCF 30/20

    ArtNo: 14522828

    Amperage (A)
    10,4/5,2
    No of phases
    3
    Power (kW)
    3
    Power Voltage (V)
    230/460
    Weight (kg)
    85
    FAN NCF 30/25

    ArtNo: 14522928

    Amperage (A)
    13,6/6,8
    Noise level (dB(A))
    74 db(A) at 4000 m³/h
    No of phases
    3
    Power (kW)
    4
    Power Voltage (V)
    230/460
    Weight (kg)
    105
    FAN NCF 40/25

    ArtNo: 14523028

    Power Voltage (V)
    230/460
    No of phases
    3
    Amperage (A)
    17,0/8,5
    Noise level (dB(A))
    75 db(A) at 4000 m³/h
    Weight (kg)
    110
    Power (kW)
    5,5
    FAN NCF 50/25

    ArtNo: 14523128

    Amperage (A)
    17,0/8,5
    Noise level (dB(A))
    78 db(A) at 3500 m³/h
    No of phases
    3
    Power (kW)
    5,5
    Power Voltage (V)
    230/460
    Weight (kg)
    112
    FAN NCF 80/20

    ArtNo: 14523228

    Amperage (A)
    23,8
    Noise level (dB(A))
    77 db(A) at 6000 m³/h
    No of phases
    3
    Power (kW)
    7,5
    Power Voltage (V)
    230/460
    Weight (kg)
    150
    Fan NCF 120/15

    ArtNo: 14523328

    Amperage (A)
    34,8
    Noise level (dB(A))
    85 db(A) at 10000 m³/h
    No of phases
    3
    Power (kW)
    11
    Power Voltage (V)
    230/460
    Weight (kg)
    161
    FAN NCF 30/20

    ArtNo: 14523728

    Amperage (A)
    4,2
    No of phases
    3
    Power (kW)
    3
    Power Voltage (V)
    575
    Weight (kg)
    85
    FAN NCF 30/25

    ArtNo: 14523828

    Amperage (A)
    5,5
    Noise level (dB(A))
    74 db(A) at 4000 m³/h
    No of phases
    3
    Power (kW)
    4
    Power Voltage (V)
    575
    Weight (kg)
    105
    FAN NCF 40/25

    ArtNo: 14523928

    Amperage (A)
    6,8
    Noise level (dB(A))
    75 db(A) at 4000 m³/h
    No of phases
    3
    Power (kW)
    5,5
    Power Voltage (V)
    575
    Weight (kg)
    110
    FAN NCF 50/25

    ArtNo: 14524028

    Amperage (A)
    6,8
    Noise level (dB(A))
    78 db(A) at 3500 m³/h
    No of phases
    3
    Power (kW)
    5,5
    Power Voltage (V)
    575
    Weight (kg)
    112
    FAN NCF 80/20

    ArtNo: 14524128

    Amperage (A)
    9,5
    Noise level (dB(A))
    77 db(A) at 6000 m³/h
    No of phases
    3
    Power (kW)
    7,5
    Power Voltage (V)
    575
    Weight (kg)
    150
    FAN NCF 120/15

    ArtNo: 14524228

    Amperage (A)
    15
    Noise level (dB(A))
    85 db(A) at 10000 m³/h
    No of phases
    3
    Power (kW)
    11
    Power Voltage (V)
    575
    Weight (kg)
    161
    Fan NCF 120/25

    ArtNo: 14524328

    Amperage (A)
    19,4
    Noise level (dB(A))
    82 db(A) at 8000 m³/h
    No of phases
    3
    Power (kW)
    15
    Power Voltage (V)
    575
    Weight (kg)
    232
    FAN NCF 160/25

    ArtNo: 14524428

    Amperage (A)
    24,0
    Noise level (dB(A))
    84 db(A) at 10000 m³/h
    No of phases
    3
    Power (kW)
    18,5
    Power Voltage (V)
    575
    Weight (kg)
    292
    FAN NCF 30/25

    ArtNo: 14552128

    Power Voltage (V)
    380
    Amperage (A)
    8,27
    Noise level (dB(A))
    75 db(A) at 3000 m³/h
    Weight (kg)
    105
    Outlet
    400
    Power (kW)
    4
    FAN NCF 40/25

    ArtNo: 14552228

    Power Voltage (V)
    380
    Amperage (A)
    10,8
    Noise level (dB(A))
    75 db(A) at 4000 m³/h
    Weight (kg)
    110
    Power (kW)
    5,5
    FAN NCF 50/25

    ArtNo: 14552328

    Power Voltage (V)
    380
    Amperage (A)
    10,8
    Noise level (dB(A))
    78 db(A) at 4000 m³/h
    Weight (kg)
    112
    Power (kW)
    5,5
    FAN NCF 80/20

    ArtNo: 14552428

    Power Voltage (V)
    380
    Amperage (A)
    14,5
    Noise level (dB(A))
    78 db(A) at 5000 m³/h
    Weight (kg)
    150
    Power (kW)
    7,5
    FAN NCF 120/25

    ArtNo: 14552528

    Power Voltage (V)
    380
    Amperage (A)
    27,5
    Noise level (dB(A))
    82 db(A) at 8000 m³/h
    Weight (kg)
    232
    Outlet
    400
    Power (kW)
    15
    NCF 160/25

    ArtNo: 14552628

    Power Voltage (V)
    380
    Power (kW)
    18,5

Accessories for this product 40

Inlet adap. d250,30/15,40/25,50/25
ArtNo: 14374438

Inlet adap. d250,30/15,40/25,50/25

Inlet adapter d315, 30/25
ArtNo: 14374439

Inlet adapter d315, 30/25

Inlet adapter d400, 80/20, 120/25
ArtNo: 14374440

Inlet adapter d400, 80/20, 120/25

Inlet adapter d500, 120/15, 160/25
ArtNo: 14374441

Inlet adapter d500, 120/15, 160/25

Outl. adap.288x205 d315,30/15,40/25
ArtNo: 14374442

Outl. adap.288x205 d315,30/15,40/25

Outlet adapter 322x229 d400, 30/25
ArtNo: 14374443

Outlet adapter 322x229 d400, 30/25

Outl.adap.361x256 d400,80/20,120/25
ArtNo: 14374444

Outl.adap.361x256 d400,80/20,120/25

Outl.adap.453x322d500,120/15,160/25
ArtNo: 14374445

Outl.adap.453x322d500,120/15,160/25

Outl.adap.256x183 d250, 50/25,30/20
ArtNo: 14374446

Outl.adap.256x183 d250, 50/25,30/20

Flex.inl.ad..d250,30/15,40/25,50/25
ArtNo: 14374447

Flex.inl.ad..d250,30/15,40/25,50/25

Flexible inlet adapter d315, 30/25
ArtNo: 14374448

Flexible inlet adapter d315, 30/25

Flex.inlet.adap.d400, 80/20, 120/25
ArtNo: 14374449

Flex.inlet.adap.d400, 80/20, 120/25

Flex.inlet.adap.d500,120/15,160/25
ArtNo: 14374450

Flex.inlet.adap.d500,120/15,160/25

Flex.out.a.288x205 d315,30/15,40/25
ArtNo: 14374451

Flex.out.a.288x205 d315,30/15,40/25

Flex.outlet adap.322x229 d400,30/25
ArtNo: 14374452

Flex.outlet adap.322x229 d400,30/25

Flex.out.a.361x256d400,80/20,120/25
ArtNo: 14374453

Flex.out.a.361x256d400,80/20,120/25

Flex.ou.a.453x322d500,120/15,160/25
ArtNo: 14374454

Flex.ou.a.453x322d500,120/15,160/25

Flex.ou.a.256x183 d250, 50/25,30/20
ArtNo: 14374455

Flex.ou.a.256x183 d250, 50/25,30/20

Inl.guardnet d250,30/15,40/25,50/25
ArtNo: 14374456

Inl.guardnet d250,30/15,40/25,50/25

Inlet guard net d315, 30/25
ArtNo: 14374457

Inlet guard net d315, 30/25

Inlet guard net d400, 80/20, 120/25
ArtNo: 14374458

Inlet guard net d400, 80/20, 120/25

Inlet guard net d500,120/15,160/25
ArtNo: 14374459

Inlet guard net d500,120/15,160/25

Outlet guard net, 30/15, 40/25
ArtNo: 14374460

Outlet guard net, 30/15, 40/25

Outlet guard net, 30/25
ArtNo: 14374461

Outlet guard net, 30/25

Outlet guard net, 80/20, 120/25
ArtNo: 14374462

Outlet guard net, 80/20, 120/25

Outlet guard net, 120/15, 160/25
ArtNo: 14374463

Outlet guard net, 120/15, 160/25

Outlet guard net, 50/25
ArtNo: 14374464

Outlet guard net, 50/25

Vibration absorber AM 30, 1 set
ArtNo: 14374628

Vibration absorber AM 30, 1 set

Vibration absorber AM 25, 1 set
ArtNo: 14374629

Vibration absorber AM 25, 1 set

Vibration absorber AM 50, 1 set
ArtNo: 14374630

Vibration absorber AM 50, 1 set

Inlet adapter d250, 30/20
ArtNo: 14375076

Inlet adapter d250, 30/20

Fan starter 5.5kW (2,2 - 5,5 kW motor power)
ArtNo: 14514837

Fan starter 5.5kW

Fan starter 11kW (4,0 - 11,0 kW motor power)
ArtNo: 14514937

Fan starter 11kW

Fan starter 18.5kW (15,0 - 18,5 kW motor power)
ArtNo: 14515037

Fan starter 18.5kW

Fan Inverter for 5,5 kW motor power
ArtNo: 14522037

Fan inverter 5,5

Fan Inverter for 7,5 kW motor power
ArtNo: 14522137

Fan inverter 7,5

Fan Inverter for 11 kW motor power
ArtNo: 14522237

Fan inverter 11

Fan Inverter for 15 kW motor power
ArtNo: 14522637

Fan inverter 15

Fan Inverter for 18,5 kW motor power
ArtNo: 14525137

Fan inverter 18,5

Fan Inverter for 22 kW motor power
ArtNo: 14525237

Fan inverter 22
